Intel HD Graphics 4600

Intel HD Graphics 4600 (GT2) är en integrerad grafikkrets i Intels Haswell-processorer som lanseras 2013 (4:e generationens Core). Klockfrekvensen justeras automatiskt med Turbo Boost-tekniken. Beroende på processormodell kan grund- och turbofrekvenserna skilja sig mycket, vilket har stor effekt på prestandan.
De exakta funktionerna har inte offentliggjorts i skrivande stund, men det har bekräftats att HD 4600 stöder DirectX 11.1, OpenCL 1.2 och OpenGL 4.0. HD 4600 har också en förbättrad avkodare för 4K-video samt videokodaren Quick Sync.
HD Graphics förväntas ha 20 EUs (Execution Units), jämfört med HD 4000 som har 16, vilket bör förbättra prestandan jämfört med föregångaren med ca 20 %. Det skulle innebära en prestanda i nivå med ett äldre dedikerat grafikkort i mellanklassen, som GeForce GT 525M.
Tack vare tillverkningsprocessen på 22nm med Tri-Gate-designen bör strömförbrukningen vara relativt låg. TDP för hela kretsen inklusive processor, grafikkort och minneskontroller varierar mellan 15 watt upp till 57 watt i modellerna för bärbara datorer.
HD Graphics Serie
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Kodnamn | Haswell GT2 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Arkitektur | Gen. 7.5 Haswell | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| iGPU | Integrated Graphics | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pipelines | 20 - unified | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Kärnhastighet | 200 - 1350 (Boost) MHz | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Minnesbuss | 64/128 Bit | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Delat minne | ja | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| API | DirectX 11.1, Shader 5.0, OpenGL 4.0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Teknologi | 22 nm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Funktioner | QuickSync | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lanseringsdatum | 01.06.2013 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||
Prestandatester
3DM Vant. Perf. total +
specvp11 snx-01 +
specvp12 sw-03 +
Cinebench R15 OpenGL 64 Bit +
GFXBench T-Rex HD Offscreen C24Z16 +
* Mindre antal betyder högre prestanda
Speltester
Följande tester/benchmarks kommer från våra laptoprecensioner. Prestandan beror på typen av grafikminne, klockfrekvens, processor, systeminställningar och operativsystem. Resultaten är därför inte nödvändigtvis representativa för alla bärbara datorer med denna GPU. För detaljerad information om resultaten, klicka på fps-värdet.

New World
2021
Days Gone
2021
Yakuza Like a Dragon
2020
Hunt Showdown
2020
Escape from Tarkov
2020
Need for Speed Heat
2019
FIFA 20
2019
Borderlands 3
2019
Control
2019
F1 2019
2019
Anno 1800
2019
The Division 2
2019
Dirt Rally 2.0
2019
Anthem
2019
Far Cry New Dawn
2019
Metro Exodus
2019
Apex Legends
2019
Just Cause 4
2018
Darksiders III
2018
Battlefield V
2018
Farming Simulator 19
2018
Fallout 76
2018
Hitman 2
2018
Forza Horizon 4
2018
FIFA 19
2018
F1 2018
2018
Monster Hunter World
2018
The Crew 2
2018
Far Cry 5
2018
X-Plane 11.11
2018
Fortnite
2018
Call of Duty WWII
2017
Destiny 2
2017
ELEX
2017
The Evil Within 2
2017
FIFA 18
2017
Ark Survival Evolved
2017
F1 2017
2017
Team Fortress 2
2017
Dirt 4
2017
Rocket League
2017
Prey
2017
For Honor
2017
Resident Evil 7
2017
Dishonored 2
2016
Titanfall 2
2016
Farming Simulator 17
2016
Battlefield 1
2016
Civilization 6
2016
Mafia 3
2016
FIFA 17
2016
No Man's Sky
2016
Overwatch
2016
Need for Speed 2016
2016
Hitman 2016
2016
The Division
2016
Far Cry Primal
2016
XCOM 2
2016
Rainbow Six Siege
2015
Just Cause 3
2015
Fallout 4
2015
Anno 2205
2015
FIFA 16
2015
World of Warships
2015
Metal Gear Solid V
2015
Mad Max
2015
Dota 2 Reborn
2015
The Witcher 3
2015
Dirt Rally
2015
GTA V
2015
Battlefield Hardline
2015
Evolve
2015
The Crew
2014
Far Cry 4
2014
F1 2014
2014
The Evil Within
2014
Ryse: Son of Rome
2014
Alien: Isolation
2014
Fifa 15
2014
Sims 4
2014
Risen 3: Titan Lords
2014
GRID: Autosport
2014
Watch Dogs
2014
Titanfall
2014
Thief
2014
X-Plane 10.25
2013
Call of Duty: Ghosts
2013
Battlefield 4
2013
F1 2013
2013
Fifa 14
2013
Total War: Rome II
2013
Saints Row IV
2013
Company of Heroes 2
2013
Metro: Last Light
2013
BioShock Infinite
2013
SimCity
2013
Tomb Raider
2013
Crysis 3
2013
Dead Space 3
2013
Far Cry 3
2012
Assassin´s Creed III
2012
Hitman: Absolution
2012
Dishonored
2012
Counter-Strike: GO
2012
Sleeping Dogs
2012
Max Payne 3
2012
Dirt Showdown
2012
Diablo III
2012
Risen 2: Dark Waters
2012
Mass Effect 3
2012
Alan Wake
2012
Anno 2070
2011
Battlefield 3
2011
Batman: Arkham City
2011
Dirt 3
2011
Mafia 2
2010
StarCraft 2
2010
Metro 2033
2010För att se fler spel som kan vara spelbara och se en lista med alla spel och grafikkort, besök vår spellista
