AMD Steam Deck OLED APU

AMD Steam Deck OLED APU

AMD Custom APU 0405 är ett 6 nm-chip i Steam Deck OLED-spelkonsolen. Processorn kallas "6 nm AMD APU" av Valve och erbjuder fyra Zen 2-kärnor som är klockade från 2,4 - 3,6 GHz.

CPU-prestandan liknar den äldre AMD Ryzen 3 4300U med också fyra Zen 2-kärnor (ingen SMT) men något högre klockfrekvenser (2,7 - 3,7 GHz) och vanligtvis bättre kylning. Jämfört med LCD-versionen, som fortfarande tillverkas i 7 nm, förändras prestandan knappast.

Den integrerade GPU:n använder den moderna RDNA 2-arkitekturen med 8 CU:er, som så att säga sitter mellan en Radeon 660M och 680M.

Chipet tillverkas hos TSMC i N6-processen (6nm) och har en TDP på 15 watt. I mjukvaran kan APU:n också reduceras till upp till 4 watt för betydligt längre batteritid.

SerieAMD Renoir (Ryzen 4000 APU)
KodnamnVan Gogh (Custom)
Klockfrekvens2400 - 3500 MHz
Level 1-cache256 KB
Level 2-cache2 MB
Level 3-cache4 MB
Antal kärnor / trådar4 / 8
4 x 3.6 GHz AMD Zen 2
Strömförbrukning (TDP = Thermal Design Power)15 Watt
Tillverkningsprocess6 nm
FunktionerDDR4-3200/LPDDR4-4266 RAM, PCIe 3, MMX, SSE, SSE2, SSE3, SSSE3, SSE4A, SSE4.1, SSE4.2, AVX, AVX2, BMI2, ABM, FMA, ADX, SMEP, SMAP, CPB, AES-NI, RDRAND, RDSEED, SHA, SME
GPUAMD Radeon Steam Deck 8CU (1000 - 1600 MHz)
64-bit64-bitsstöd
Architecturex86
Lanseringsdatum11/09/2023
Produktlänkwww.steamdeck.com

Prestandatester

Cinebench R23 - Cinebench R23 Multi Core
3984 Points (4%)
AMD E1-2100
202 -95%
...
3571 -10%
3603 -10%
3603 -10%
Intel Core i7-1065G7
3615 -9%
Intel Core i5-8259U
3792 -5%
Intel Core i5-1035G4
3800 -5%
3866 -3%
AMD Ryzen 7 3750H
3897 -2%
AMD Ryzen 5 3550H
3930 -1%
AMD Steam Deck OLED APU
3984
Intel Core i5-1035G1
4027 1%
Intel Core i5-8257U
4033 1%
Intel Core i7-10610U
4049 2%
Intel Core i7-10710U
4079 2%
4112 3%
4311 8%
Intel Core i5-8400H
4657 17%
4724 19%
4880 22%
...
32782 723%
max:
107681 2603%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
357 Points (40%)
Cinebench R20 - Cinebench R20 CPU (Multi Core)
1521 Points (4%)
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
689 Points (4%)
AMD A4-1200
31 -96%
...
Intel Core i7-4800MQ
648 -6%
Intel Core i7-1065G7
648 -6%
Intel Core i7-4810MQ
650 -6%
AMD Ryzen Embedded V1605B
654 -5%
AMD Ryzen 7 PRO 3700U
658 -4%
Intel Core i5-1035G7
662 -4%
666 -3%
Intel Core i7-5850HQ
667 -3%
671 -3%
AMD Steam Deck OLED APU
689
AMD Ryzen 5 3580U
693 1%
Intel Core i7-4980HQ
694 1%
Intel Core i7-4910MQ
696 1%
703 2%
707 3%
Intel Core i7-4940MX
708 3%
Intel Core i7-7820HQ
710 3%
Intel Core i5-8305G
710 3%
Intel Core i7-6770HQ
711 3%
...
5600 713%
max:
15842 2199%
0%
100%
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
19684 MIPS (11%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
3653 MIPS (44%)
Geekbench 6.2 - Geekbench 6.2 Single-Core
1348 poäng (41%)
Geekbench 6.2 - Geekbench 6.2 Multi-Core
4587 poäng (18%)
662 -86%
Intel Pentium Gold 4425Y
763 -83%
1332 -71%
1660 -64%
2024 -56%
2803 -39%
2958 -36%
3012 -34%
4090 -11%
AMD Steam Deck OLED APU
4587
4727 3%
Intel Core i5-8400H
4963 8%
5213 14%
5340 16%
5548 21%
Intel Core i7-11390H
5630 23%
5722 25%
6317 38%
6336 38%
...
21254 363%
max:
25365 453%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
1486 poäng (63%)
AMD E1-2100
125 -92%
...
1460 -2%
1464 -1%
1467 -1%
1471 -1%
1477 -1%
1478 -1%
1478 -1%
1480 0%
AMD Ryzen 9 5900HS
1485 0%
AMD Steam Deck OLED APU
1486
1489 0%
1492 0%
1493 0%
1497 1%
1502 1%
1507 1%
1511 2%
1520 2%
1520 2%
...
2342 58%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
4457 poäng (8%)
AMD E1-2100
238.5 -95%
...
Intel Core i7-8557U
4119 -8%
Intel Core i7-10610U
4134 -7%
Intel Core i7-1065G7
4215 -5%
4332 -3%
4350 -2%
4351 -2%
Intel Core i5-8400H
4352 -2%
4370 -2%
Intel Core i7-1068G7
4449 0%
AMD Steam Deck OLED APU
4457
Intel Core i5-1038NG7
4564 2%
4642 4%
4644 4%
AMD Ryzen 5 PRO 4650U
4646 4%
4663 5%
4774 7%
4802 8%
4820 8%
Intel Core i7-8850H
4908 10%
...
22938 415%
max:
55811 1152%
0%
100%
WebXPRT 4 - WebXPRT 4 Score
107 Points (31%)
CrossMark - CrossMark Overall
840 Points (32%)
Power Consumption - Prime95 Power Consumption - external Monitor *
26.1 Watt (5%)
0510152025Tooltip
Power Consumption - Idle Power Consumption - external Monitor *
6.5 Watt (5%)
01234567Tooltip
- Bredd på benchmark-värden för det här grafikkortet
- Genomsnittliga benchmark-värden för det här grafikkortet
* Smaller numbers mean a higher performance

v1.26
log 26. 13:04:19

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sun, 25 Feb 2024 05:39:22 +0100 +0.001s ... 0.001s

#3 composed specs +0.01s ... 0.011s

#4 did output specs +0s ... 0.011s

#5 getting avg benchmarks for device 17354 +0.003s ... 0.014s

#6 got single benchmarks 17354 +0.009s ... 0.024s

#7 got avg benchmarks for devices +0s ... 0.024s

#8 min, max, avg, median took s +0.268s ... 0.291s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.291s

#10 return log +0s ... 0.291s
