Intel Core i5-3320M

Intel 3320M

Intel Core i5-3320M är en tvåkärnig CPU för bärbara datorer från Intels Ivy Bridge-familj. Processorn stöder HyperThreading, vilket betyder att de två kärnorna kan hantera fyra trådar parallellt. Precis som den Sandy-Bridge-baserade föregångaren Core i5-2520M har den 3 MB L3-cache (jämfört med i7-serien som har 4 MB).

Varje kärna har en bashastighet på 2,6 GHz men kan dynamiskt öka klockhastigheten med Turbo Boost upp till 3,1 GHz (med 2 aktiva kärnor) och 3,3 GHz (med 1 aktiv kärna).  Vid lanseringen var den näst snabbast i mobila Core i5-serien, efter i5-3360M.

Ivy Bridge är en förbättrad och förminskad version av Sandy Bridge med förbättringar i både GPU- och CPU-prestandan. Tillverkningsprocessen är 22nm istället för föregångarens 32nm.

Ivy Bridge-arkitekturen introducerade även "3D-transistorer", som förbättrar effektiviteten jämfört med Sandy Bridge-processorer med samma klockfrekvens. Andra nya funktioner är PCI Express 3.0 och stöd för DDR3 (L) -1600.

Prestandan med en Core i5-3320M är något bättre än motsvarande Sandy Bridge-CPU tack vare små förbättringar i arkitekturen och bör ungefär motsvara förra generationens i7-2640M.

Den integrerade grafikdelen HD Graphics 4000 har 16 exekveringsenheter (EUs) med hastigheter på mellan 650 MHz och 1200 MHz (med Turbo Boost).

Precis som de flesta andra tvåkärniga Ivy Bridge-processorerna har i5-3320M en TDP på ​​35 W.

SerieIntel Core i5
KodnamnIvy Bridge

Serie: Core i5 Ivy Bridge

Intel Core i5-3380M2.9 - 3.6 GHz2 / 4 cores3 MB L3
Intel Core i5-3360M2.8 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-3340M2.7 - 3.4 GHz2 / 4 cores3 MB L3
Intel Core i5-3320M « 2.6 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-3230M2.6 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-3210M2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-3437U1.9 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-3427U1.8 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-3337U1.8 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-3317U1.7 - 2.6 GHz2 / 4 cores3 MB L3
Intel Core i5-3439Y1.5 - 2.3 GHz2 / 4 cores3 MB L3
Intel Core i5-3339Y1.5 - 2 GHz2 / 4 cores3 MB L3
Klockfrekvens2600 - 3300 MHz
Level 1-cache128 KB
Level 2-cache512 KB
Level 3-cache3 MB
Antal kärnor / trådar2 / 4
Strömförbrukning (TDP = Thermal Design Power)35 Watt
Tillverkningsprocess22 nm
FunktionerHD Graphics 4000 (650-1200MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1200 MHz)
64-bit64-bitsstöd
Architecturex86
Pris från$225 U.S.
Lanseringsdatum06/03/2012
Produktlänkark.intel.com

Prestandatester

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.04     avg: 3.1     median: 3.1 (4%)     max: 3.1 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.31     avg: 1.3     median: 1.3 (33%)     max: 1.35 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4292     avg: 4407     median: 4415.5 (27%)     max: 4465 poäng
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 9473     avg: 9554     median: 9550 (7%)     max: 9683 poäng
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 11505     avg: 11699     median: 11667 (8%)     max: 11913 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5380     avg: 5561     median: 5588 (7%)     max: 5646 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 499.2     avg: 537     median: 540 (6%)     max: 557 s
wPrime 2.10 - wPrime 2.0 32m *
min: 15.85     avg: 17.6     median: 17.4 (3%)     max: 20.9 s
WinRAR - WinRAR 4.0
min: 2522     avg: 2915     median: 2707 (4%)     max: 3361 poäng
X264 HD Benchmark 4.0 - x264 Pass 2
min: 16.9     avg: 17.5     median: 17.5 (6%)     max: 17.74 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 86.8     avg: 91     median: 91 (21%)     max: 94 fps
TrueCrypt - TrueCrypt Serpent
min: 0.1572     avg: 0.2     median: 0.2 (0%)     max: 0.161 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.267     avg: 0.3     median: 0.3 (5%)     max: 0.276 GB/s
TrueCrypt - TrueCrypt AES
min: 0.2988     avg: 1.4     median: 1.5 (4%)     max: 1.5 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3727     avg: 3770     median: 3767 (8%)     max: 3808 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 11     avg: 13.2     median: 11.9 (3%)     max: 28.84 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 26     avg: 30     median: 27 (1%)     max: 58.8 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 611     avg: 678     median: 636 (3%)     max: 1122 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 53130     avg: 57674     median: 57480 (27%)     max: 62610 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 37700     avg: 38286     median: 37920 (29%)     max: 39380 MFLOPS
Windows 7 Experience Index - Win7 CPU
min: 7.1     avg: 7.2     median: 7.2 (92%)     max: 7.2 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 9831     avg: 10105     median: 10094.5 (9%)     max: 10559 Points
3DMark 11 - 3DM11 Performance Physics
min: 3138     avg: 3571     median: 3501 (9%)     max: 4041 Points
3DMark - 3DMark Ice Storm Physics
min: 24617     avg: 27316     median: 27316 (22%)     max: 30015 Points
3DMark - 3DMark Cloud Gate Physics
min: 2720     avg: 2721     median: 2721 (7%)     max: 2722 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 4040     avg: 4064     median: 4063.5 (7%)     max: 4087 Points
- Bredd på benchmark-värden för det här grafikkortet
- Genomsnittliga benchmark-värden för det här grafikkortet
* Smaller numbers mean a higher performance
